| Video Mode |
TVI, CVI, AHD & CVBS switchable |
| Pick-up Element |
1/ 2.5” CMOS image sensor |
| Number of Pixels |
2560(H) x 1920 (V) |
| Video Frame Rate |
5MP@20fps |
| Min. Illumination |
0.1 Lux / F1.8, 0 Lux (IR LED ON) |
| S/N Ratio |
More than 48dB (AGC OFF) |
| Shutter Speed |
1/30 (1/25) sec ~ 1/ 60000 (1/ 50000) sec |
| Lens |
f3.6mm / F1.8 |
| Lens Angle |
96° (Horizontal) / 50° (Vertical) / 116° (Diagonal) |
| IR LED |
2 units |
| IR Effective Distance |
Up to 50 meters |
| IR Shift |
YES |
| Day & Night Mode |
YES |
| Noise Reduction |
YES |
| IRIS Mode |
AES |
| White Balance |
AUTO |
| AGC |
AUTO |
| Sharpness |
Adjustable |
| Flickerless |
50HZ / 60HZ / OFF |
| DWDR |
YES |
| BLC |
Adjustable |
| IP Rating |
IP66 |
| Operating Temperature |
-20℃ ~ 40℃ |
| Operating Humidity |
90% or less relative humidity |
| Power Source (±10%) |
DC12V / 0.5A |
| Current Consumption (±10%) |
100mA (IR lED OFF); 240mA (IR LED ON) |
| Net Weight (kg) |
0.36 |
