| Pick-up Element |
1/ 2.7” CMOS image sensor |
| Number of Pixels |
1936(H) x 1096(V) |
| Video Frame Rate |
1080P@30fps / 1080P@25fps |
| Min. Illumination |
0.1 Lux / F1.8, 0 Lux (IR LED ON) |
| S/N Ratio |
More than 48dB (AGC OFF) |
| Shutter Speed |
1/30 (1/25) sec ~ 1/50000 sec |
| Lens |
f3.6mm / F1.8 |
| Lens Angle |
89° (Horizontal) / 46° (Vertical) / 108° (Diagonal) |
| IR LED |
2 units |
| IR Effective Distance |
Up to 25 meters |
| IR Shift |
YES |
| Day & Night Mode |
YES |
| Noise Reduction |
YES |
| IRIS Mode |
AES |
| White Balance |
AUTO / INDOOR / OUTDOOR / MANUAL |
| AGC |
Adjustable |
| Sharpness |
Adjustable |
| Flickerless |
50HZ / 60HZ / OFF |
| BLC |
Adjustable |
| DWDR |
YES |
| IP Rating |
IP66 |
| Operating Temperature |
-20℃ ~ 40℃ |
| Operating Humidity |
90% or less relative humidity |
| Power Source (±10%) |
DC12V / 0.5A |
| Current Consumption (±10%) |
95mA (IR lED OFF); 265mA (IR LED ON) |
| Net Weight (kg) |
0.17 |
