| Network Compression |
H.265 / H.264 / MJPEG |
| Video Resolution |
1920 x 1080 / 1280 x 720 / 720 x 480 / 352 x 240 |
| Frame Rate |
30fps |
| Multiple Video Streaming |
4 (H.265 / H.264 /MJPEG) |
| Image Sensor |
1/2.9" SONY CMOS image sensor |
| Min Illumination |
0.1 Lux / F1.8, 0 Lux (IR LED ON) |
| Shutter Speed |
1/2 to 1/10,000 sec |
| S/N Ratio |
More than 48dB (AGC off) |
| Lens |
f3.6mm / F1.8 |
| Viewing Angle |
89° (Horizontal) / 46° (Vertical) / 108° (Diagonal) |
| IR LED |
2 Units |
| IR Effective Distance |
Up to 25 meters |
| IR Shift |
YES |
| Smart Light Control |
YES |
| White Balance |
ATW |
| AGC |
Auto |
| IRIS Mode |
AES |
| Sharpness |
YES |
| DWDR |
YES |
| POE |
YES (IEEE 802.3af) |
| LAN Speed |
10/100 Based-T Ethernet |
| ONVIF Compatible |
YES (Profile S) |
| Privacy Mask |
YES |
| Vertical View Mode |
YES |
| Weather-proof |
IP66 |
| Operating Temperature |
-40℃ ~ 50℃ |
| Operating Humidity |
90% or less relative humidity |
| Power Source (±10%) |
12V / 0.5A |
| Current Consumption (±10%) |
120mA (IR OFF) / 280mA (IR ON) |
| Power Consumption (±10%) |
PoE & PoN: 4.2W; DC adapter: 3.5W |
| Net Weight (kg) |
0.39 |
